Get Control E84 - Port sensors tied into E84 signals 4 - Presence sensor(s) deactivated during Unload, but placement sensor(s) is not; Emergency Stop

Handheld Tester Emulator Test Suite Worksheet
3
PAGE 119
[P] [F] P. Port sensors tied into E84 signals 4 - Presence sensor(s) deactivated during Unload, but
placement sensor(s) is not: All steps must occur in the prescribed order to pass:
1. Activate both the placement and presence sensors on the loadport associated with the E84
interface being tested
2. Verify that the HO_AVBL signal is ON on the equipment
3. Set the CS_0 signal ON and CS_1 signal OFF on the E84 HHT
4. Set the VALID signal ON on the E84 HHT
5. Verify that the equipment turns the U_REQ signal ON
6. Set the TR_REQ signal ON on the E84 HHT
7. Verify that the equipment turns the READY signal ON
8. Set the BUSY signal ON on the E84 HHT and deactivate the presence sensor(s) only from the
loadport associated with the E84 interface being tested
9. Verify that the equipment does NOT turn the U_REQ signal OFF
10. After exceeding the TP3 time, verify that the equipment indicates a TP3 timeout error on the
User Interface
Notes:
Handheld Tester Emulator Test Suite Worksheet
3
PAGE 120
[P] [F] Q. Emergency Stop: All steps must occur in the prescribed order to pass:
1. Place a FOUP on the loadport associated with the E84 interface being tested
2. Verify that the HO_AVBL signal is ON on the equipment
3. Set the CS_0 signal ON and CS_1 signal OFF on the E84 HHT
4. Set the VALID signal ON on the E84 HHT
5. Verify that the equipment turns the U_REQ signal ON
6. Set the TR_REQ signal ON on the E84 HHT
7. Verify that the equipment turns the READY signal ON
8. Set the BUSY signal ON on the E84 HHT
9. Press the Emergency Stop (E-Stop) button on the equipment
10. Verify that the equipment turns the ES signal OFF
11. Set BUSY, TR_REQ, VALID and CS_0 signals OFF on the E84 HHT.
12. Clear the E-Stop condition and verify that the equipment turns the ES signal ON
Notes:
