golmar NEXA Series User Manual

52
WIRING DIAGRAMS
Combined with Nexa Modular / Nexa Stainless Steel panels:
CV10I1 I2
P1
CN1
~1~2
Door panels with
EL655 sound module
N3301
access control module
SEC
~~
PRI
~~
Main
(*)
Door panels with
1EL65 sound module
N3301
access control module
TF-104
transformer
TF-104
transformer
SEC
~~
PRI
~~
Main
Audio door entry systems with one access door and 4+'n' installation.
Audio door entry systems with several access doors and 4+'n' installation.
5 3 CVCVC2NC1 NC2
CN1
P
~ ~
C1NA1
NA2
PL1 PL2
-
CV10I1 I2
P1
CN1
~1~2
5 3 CVCV
C2NC1 NC2
CN1
P
~ ~
C1NA1
NA2
PL1 PL2
-
CO
(*)
(*) Lock release systems connected to audio door entry systems with 4+'n' installation operate at 12V AC: fit the varistor
supplied with the access control module directly to the terminals of the lock release.
AUDIO AND VIDEO DOOR ENTRY SYSTEM - ACCESS CONTROL
