35
Microphone.
Front.
Sound module buttons (x2).
Connection block.
Cn2 button connector.
Back.
: Negative
:
Contact C for electric lock. Relay 3.
: Contact N.O. for electric lock. Relay 3.
: Positive, negative.
: Audio and digital communication.
: Video signal input.
: Video signal output.
: Negative.
Colour camera. (Only the EL632 R5 module)P/T .
CV1
CV2
+,
A/D
Vi+,Vi-
Vo+,Vo-
_
Telephone speaker volume control potentiometer.
LEDs (visual indications for people with impaired hearing).
Cn7 NEXA Bus connector.
Description of the EL632 R5 - EL642 5 sound module:P/T R
Sw1 DIP switch.
Door panel speaker volume control potentiometer.
Button number.
AUDIO AND VIDEO DOOR ENTRY SYSTEM - ACCESS CONTROL
DESCRIPTION OF THE SOUND MODULES
_
_
Speaker.
LEDs. (Only function with EL632 R5 P/T module).
Telephone speaker volume control potentiometer.
Door panel speaker volume control potentiometer.
