golmar NEXA Series User Manual

51
WIRING DIAGRAMS
Combined with Nexa Modular / Nexa Stainless Steel panels:
Door panels with EL63 PLUS -2 P/T
EL64 PLUS sound module2
N3301
access control module
FA-Plus or FA-Plus/C
power supply unit
C2NC1 NC2
CN1
P
~ ~
SEC
+
-
PRI
~~
Main
CN1
+
- -
+CV1CV2
Electronic or video access control systems with digital installation.
The wiring of the access control module with 'Nexa Modular/Nexa Stainless Steel' panels will vary depending on the type
of installation. Use the same power supply unit as the panels.
10
1
9
2
8
3
7
4
6
5
CN3
C1NA1 NA2
PL1 PL2
-
Door panels with EL63 R5 -2 P/T
EL64 R5 sound module2
N3301
access control module
FA-Plus/C
power supply unit
C2NC1 NC2
CN1
P
~ ~
SEC
+
-
PRI
~~
Main
CN1
+
-
+CV1CV2
C1NA1 NA2
PL1 PL2
-
-
+12
-
AUDIO AND VIDEO DOOR ENTRY SYSTEM - ACCESS CONTROL
NOTE: To connect the modules to an module, use theEL632 EL642Plus P/T , R5 P/T orPlus or EL632 EL642 R5
NEXABus hose. See p. 7 to check the wiring and p. 9 to check the wiring diagram.1 3
