Programming T-540 Plus telephones:SE
PROGRAMMING THE TELEPHONES
To programme the telephone from a general entrance door panel (if any), see p. 9.4
48
Each apartment must only have one master unit; if there are parallel units, whether monitors or telephones, they must be
configured as slaves.
Make a call to check that the telephone has been successfully programmed. Programme the other
telephones in the same way.
Once the programming has finished, set the programming switch to OFF. If this is not done, the door panel
will emit tones to indicate that the system is still in programming mode.
AUDIO AND VIDEO DOOR ENTRY SYSTEM - ACCESS CONTROL
Locate the SW2 DIP switch situated onthe top left-hand side of the back of the EL632 PLUS module and setP/T
number 2 to ON. The door panel will reproduce a sound to advise that the system has entered into
programmingmode.
In systems with more than one door panel, the programming process shall be done on the master door
panel only.
Important: .To perform this programming, the 's SW DIP switches should be set totelephone 1 OFF
Press the button of the door panel that will call this telephone.
At this moment, the door panel and handset will emit a number of tones (the
LED on the telephone will blink red).
To programme the telephone as , press button and the LEDSlave + Intercom
will blink (green) once. Then press button for 3 seconds (the telephone's
LED will illuminate red).
M
S
SI
Switch off the telephone to be programmed.
Once switched off, press the door release button.
While keeping the door release button pressed, switch on the telephone.
To show that the system is ready for programming, the door panel and the
telephone handset will emit a number of tones (the LED on the telephone will
illuminate red), enabling the door release button to be released. To establish
audio communication with the door panel, lift the handset.
To programme the telephone as , press button for 3 seconds (the telephone'sMaster
LED will illuminate red).
To programme it as , press button once, and the status LED willSlave 1
blink (green) once. Continue successively to , pressing buttonSlave 4
four times, and the status LED will blink (green) four times.
