75
Programming fields:
0
Press the key button to finish programming the field.
5 6
4
or or
0
The module comes programmed with factory settings except for the activation codes (user), which are left empty for
security reasons. For system operation tailored to the needs of the user, check all of the values in all of the fields. The
fields do not need to be programmed in numerical order.
Field “0”: Configuring the number of digits in the activation codes (user) and special codes.
(1)
2 7 1 8
Key button + key button + key button + administrator pin.
Enter programming mode:
Bear in mind the number of digits in the configured code (factory setting 2718 = 4).
(1)
Step 2: Then press the field number:
Step 1: Press the key button three times and then enter the administrator pin.
Press “0” to select field “0”.
4 5 6
Steps: Field + number of digits + key button.
or or
Then press the number of the next field to configure or press the C button
(cancel) to exit programming mode.
1 C
or
(Step 1)
(Step )2
(Step )3
(Step )4
Set the number of digits for the “user” activation codes (relay 1/relay 2/panic) and special
codes. Enter 4, 5 or 6 digits.
The factory setting has 4 digits.
To change this value, add or remove 1 or 2 zeros from the end of the existing codes, for
example:
Administrator pin 2718 ( 4 digits).factory setting
Administrator pin 27180 (5 digits).
Administrator pin 271800 (6 digits)
.
AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED DOOR PANEL
PROGRAMMING THE DOOR PANEL
