57
Sound modules
EL63 GTWIN2/
Access control module
N3301/AL
, coded module.
, ,
video door entry system with colour television camera
(non-polarised 2-wires bus).
Door panel component assembly drawing.
NEXA Bus link hose (length 50 cm).
To connect the EL632 module to the N3301/AL coded module and the EL3002GTWIN
lighting module.
Lighting module
EL3002 ( )see p. 71
DESCRIPTION OF THE DOOR PANEL
Description of the Nexa modular door panel :(Gtwin)
AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED DOOR PANEL
Aluminium panel
Electronic modules
Frame modulesEmbedding boxes
Description of the door panel
Grille modules:
N1000/AL
N1110/AL 1P.
N2220/AL 2P.
Clip-on covers: 60xx
Access control module
: N3301/AL
Nexa module separator (x2)
Fixing screws for clip-on covers (x8)
Side profile
(x2)
Side profile Door panel joining bar
*
Fixing screws for embedding box (x2)
Door panel joining bar: Enables 2 door panels to be joined.
Information modules:
N3002/AL.
*
Blank module: N3000/AL
