DESCRIPTION OF THE DOOR PANEL
56
Sound modules
EL63 PLUS P/T2
EL642/PLUS
EL632 R5 P/T
EL642/R5
Access control module
N3301/AL
, .
coded module
, video door entry system with colour television camera, 3 wires + COAX.
Door panel component assembly drawing.
Aluminium panel
Electronic modules
Frame modulesEmbedding boxes
Description of the door panel
Description of the Nexa modular door panel:
Grille modules:
N1000/AL
N1110/AL 1P.
N2220/AL 2P.
Clip-on covers: 60xx
Access control module
:
N3301/AL
Nexa module separator (x2)
Fixing screws for clip-on covers (x8)
Side profile (x2)
Side profile Door panel joining bar
*
Fixing screws for embedding box (x2)
Door panel joining bar: Enables 2 door panels to be joined.
, audio door entry system, 4 common wires.
, video door entry system with colour television camera, 5 common wires.
, audio door entry system, 5 common wires.
AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED DOOR PANEL
NEXA Bus link hose (length 50 cm).
To connect the EL632 or EL642 module to the N3301/AL coded/EL642 Plus EL632/ R5
module and the EL3002 lighting module.
Lighting module
EL3002 (see p. 7 )1
Information modules:
N3002/AL.
*
