62
Microphone.
Front.
Sound module buttons (x2).
Connection block.
C 2N button connector.
Back.
: Negative
:
Contact C for electric lock. Relay 3.
: Contact N.O. for electric lock. Relay 3.
: Positive, negative.
: Audio and digital communication.
: Video signal input.
: Video signal output.
: Negative
CV1
CV2
+,
A/D
Vi+,Vi-
Vo+,Vo-
_
Telephone speaker volume control potentiometer.
LEDs (visual indications for people with impaired hearing)
C 7N NEXA Bus connector.
Description of the EL632/R5 - EL642/R5 sound module:
S 1W DIP switch.
Door panel speaker volume control potentiometer.
Button number.
DESCRIPTION OF THE SOUND MODULES
_
_
AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED DOOR PANEL
Speaker.
LEDs.
Telephone speaker volume control potentiometer.
Door panel speaker volume control potentiometer.
Colour camera. (Only the EL632 R5 module)P/T .
LEDs
. (Only function with EL632 R5 P/T module).
