Firmware Version 1.0.3.30

GXV3240 User Guide

Page 23 of 177

INSTALLATION

EQUIPMENT PACKAGING

Table 2: GXV3240 Equipment Packaging

Main Case

1

Handset

1

Phone Cord

1

12V DC Power Adaptor

1

Ethernet Cable

1

Phone Stand

1

Wall Mount

1

Screen Cleaning Cloth

1

Quick Installation Guide

1

CONNECT YOUR PHONE
