Fail Safe setting not performed yet
Throttle or pitch control stick position or throttle limit for helicop-
ters too high
Connection between teacher and pupil transmitter disturbed
No SD or SDHC memory card in the card slot or card not readable.
The transmitter has not been used within the time set from the line
"Switch-on warning" of the "
general settings" menu. An acoustic
warning alarm is emitted, the display shows the warning symbol,
and the
WARNING LED on the right side of the On/Off switch
blinks. The transmitter will autonomously switch off after three
minutes of continued inactivity.
In case of too low battery voltage a model change is not possible for
safety reasons. The display shows a related message:
Continue (CONTINUE) or interrupte (INTERRUPT) the "Wireless
Teacher/pupil connection" used before the last switch off of the
transmitter?
Model selection
Tap on the SET button to access the menu. Now you can see the list
of the available model memories. Select the desired model memory
with the or buttons of the left or right touch-pad. Then tap on
the SET button.
To create a new model memory, select an empty model memory:
You will be requested to select one of the five available model types.
Select with the or buttons the appropriate symbol and then tap
on the SET button. The selected model memory will be installed with
the selected model type.
Fail-Safe
setup
t.b.d.
Thr
too
high!
No
pupil
signal
insert
SD card
OK
Power-on warning
is active!!!
actually not possible
voltage too low
Please select
Trainer connection?
ON OFF
Copy / Erase
Suppress menus
Suppress models
Model select
Base setup model
Model type
03
04
05
free
02
01
06
R12
free
free
free
free
M
