Assigning the switch / Selecting the announce
• In the column “ “ assign a switch (or an announce) for each
switch position
• In the column "Type" decide if the announces act globally (GL) or
according to the phase (PH)
• In the right column select the announces available in the mem-
ory
Phase setting
In this menu you can set up to seven different phases for the model
memory. Assign a name to the phases. The phase names are created
in the "General settings" menu. All the settings are dependent on
the selected phase. The state of the phase is displayed in the second
column:
Character Description
– No switch assigned
+ Phase recallable through switch
Indicates the actually active phase
Creating a phase
Select the line of the desired phase
Select the phase name
Select an optional phase timer
Set a switching timer
Set an announce
Timer 1, Timer 2, Timer 3, Lap, Time1, Time2
There are additional timers displayed in the main display of the
transmitter. These timers can be set up in the "Phase timer" menu.
The phase timers "Timer 1 ... 3" and "Time1" and "Time2" are active
only in the phase assigned. In other phases they will be held and not
displayed. The assigned start/stop switch has no function. The lap
timer works even if a phase change is activated. The lap timer can be
stopped in each phase with the central ESC button.
With the "Lap" timer you can measure the lap time through a switch.
GL
GL
GL
1
2
3
4
Announce
GL
Ty p
–––
–––
–––
–––
Phase settings
Phase assignment
Phase trim
Announce
Timers (general)
Non-delayed chan
Pha1
Pha2
Pha3
Name ph.Tim.
Pha4
Pha5
normal
Strecke
–
–
–
–
Pha1
Pha2
Pha3
Announce
Pha4
Pha5
–
–
normal
Start
Strecke
–
–
Pha1
Pha2
Pha3
Name Sw.time
Pha4
Pha5
+
+
Normal
Start
Tr a c k
–
–
0.1s
0.1s
0.1s
0.1s
0.1s
GRAUBELE
#01
2:22h
T
P
«Speed »
K78
0:00.0
0:00.0
5.5V
3.9V
0:00.0
M
Time1
00
