33028_mc_28_Teil2_jh
Profitrim
This function is for fast, direct trimming of the aileron and flap posi-
tions. The trim range of the controls is about ±25 %.
In the line "TR" determined which of the two control surfaces pairs
"AILE" and "FLAP" and which of the two possible flap functions
should be able to be trimmed.
In the line "Ctrl", define the proportional control to be used for trim-
ming. Then define a switch in the "ON / OFF" line, which is used to
globally switch this Profitrim function on and off.
Trim of the Aileron function of the aileron ("AILE")
Trim of the Flap function of the aileron ("AILE")
Trim of the Aileron function of the flaps ("FLAP")
Trim of the Flap function of the flaps ("FLAP")
Profi trim
AI
AI
FL
FL
TR
CTL
ON/OFF
OFF OFF OFF OFF
–––
–––
–––
–––
–––
SET SET SET SET
