MOTOR AND DRIVING SYSTEM CU800 Service Manual
93
No.
Part Name
Qty
Remarks
1
Motor Controller
1
2
Main Connector Assy
1
3
Aluminum Plate
1
4
Drive Motor Assy
1
5
Decelerate Box
1
6
Rear Bridge
1
7
Temperature Sensor
1
8
Phase Sensor
1
9
Dc-Dc Converter
1
10
Fuse
1
