SPECIFICATIONS CU800 Service Manual
59
Item
Standard
Limit
Front disc brake
Type
Disc outside diameter × thickness
Pad thickness inner
Pad thickness outer
Master cylinder inside diameter
Caliper cylinder inside diameter
Brake fluid type
Dual
200× 3.5 mm (7.87 × 0.14 in)
6.0 mm (0.24 in)
6.0 mm (0.24 in)
19.0mm (0.75in)
25.0mm （1.57in）
DOT 3
----
----
----
----
----
----
----
Rear disc brake
Type
Disc outside diameter × thickness
Pad thickness inner
Pad thickness outer
Master cylinder inside diameter
Caliper cylinder inside diameter
Brake fluid type
Dual
183×4 mm (7.20× 0.16in)
6.0 mm (0.24 in)
6.0 mm (0.24 in)
19.0mm (0.75in)
22.6mm （0.89in）
DOT 3
----
----
----
----
----
----
----
2.5 12V SYSTEM ELECTRICAL SPECIFICATIONS
Item
Standard
Limit
Voltage
12 V
----
Lead-acid Battery
12V，30Ah
----
Power supply
DC-DC
Output
TDC-IY-72-12
14V/500W
----
Circuit breaker
Type
Battery pack enable signal fuse
Winch controller fuse
Four-wheel drive differential control
relay fuse
Auxiliary DC jack fuse
Instrument switching power supply fuse
Horn fuse
Signal light system fuse
Low power Speed limiter
USB power socket fuse
Headlight fuse
CAN Communication Converter/ Meter/
Battery pack constant power fuse
Standby connection post fuse
Backup fuse(odometer)
Fuse
5 A×1
5 A×1
5 A×1
10A×1
5A×1
10 A×1
5 A×1
5 A×1
5 A×1
10 A×1
5 A×1
30 A×1
5 A×2
----
----
----
----
----
----
----
