GreenWorks CU800 - Bumper

MALFUNCTION INSPECTION CU800 Service Manual
189
5.8 BUMPER
Bumper(I)
No.
Part Name
Qty
Remarks
Removing the Bumper
1
Front Bumper
1
Front Bumper：GLB Green
1
2
Hexagon Flange Bolt M10×1.25×20
2
3
Plastic Plug Φ38
2
4
Protection Cover Of Front Bumper
1
5
Blanck Logo
1
6
Cross Recess Pan Head Screw M4×12
6
7
Socket Hexagon Screw M6×16
2
8
Hexagon Flange Lockunt M4
4
9
Cross Large Plate Head Screw M6×16
2
