GreenWorks CU800 - Vehicle Specifications

SPECIFICATIONS CU800 Service Manual
56
2.3 VEHICLE SPECIFICATIONS
Item
Standard
Dimensions:
Overall length
Overall width
Overall height
Seat height
Wheelbase
Minimum ground clearance
Minimum turning radius
3,000mm (118.1 in)
1,600mm（63 in）
2,050mm（80.7 in）
860mm（33.85 in）
1950mm（75.77 in）
355mm（13.98 in）
3400mm (133.86 in)
Basic weight:
795kg (1752.7 lbs)
Max. speed:
30 MPH (48.3 km/h)
Motor:
Model
Motor type
Power
Rated torque
Voltage
Frequency
Cooling mechanism
XQY-7.5-GLB
AC induction motor
7.5Kw
120N.m
51V
100Hz
Air
Controller：
Model
Curtis 1234SE_6321
350 Amp controller with multi-mode driving
and regenerative braking
Portable charger:
Model
100-240 V AC input; 86.4V DC output
(max)
Transmission:
Main gear case
Gear Shift
Gearbox Transmission Ratio
Rear Bridge Transmission Ratio
Front Bridge Transmission Ratio
Gear shift system
Direct drive with low-noise gears
Electronic Gear Select H/M/L
14.14
3.7
3.7
F, N, R gears driven by direction of electric
motor
Chassis
Frame type
Trail
Toe-in
Steel tube frame
26.0mm（1.02 in）
8～18 mm （0.31～0.71 in）
Item
Standard
