GENERAL INFORMATION CU800 Service Manual
41
⚫ Connect the charger with AC power cord, and ensure voltage and frequency of
90~265V/45~65HZ.
⚫ An extension cord or electrical outlet must accept a three-prong plug. Improper
receptacle can cause fire or personal injury.
⚫ Do not operate the charger if it has received a sharp blow, was dropped, or otherwise
damaged in any way.
⚫ Have worn, cut, or damaged power cords or wires replaced immediately.
⚫ Do not use the charger near fuels, grain dust, solvents, thinners, or other flammables.
objects. Chargers can ignite flammable materials and vapors.
⚫ Do not expose to rain or any liquid. Keep the charger dry.
⚫ Never push objects of any kind into the charger through cabinet slots. They may touch
dangerous voltage points or cause an electrical short circuit that could result in fire or
electrical shock.
⚫ Do not allow clothing, blankets, or other material to cover the charger.
⚫ Do not block or cover the charger ventilation slots. The slots provide ventilation and
protect the charger from overheating.
⚫ Install arrester for the input AC cable. Arrester will help to protect the element of the
charger and the EV, avoid the lightning strike.
⚫ Connect the charger AC supply cord to a properly grounded, three-wire outlet of the
proper voltage and frequency as shown on the charger.
⚫ Do not use an extension cord to plug the charger. Please ask the eligible electrician to
install the extension cord. Improper using the extension cord can result in fire in case
of the overheating.
⚫ Use the proper cord wire gauges for the cord length used:
To reduce the risk of electric shock, the battery charger must be grounded. The charger is
equipped with an AC electric cord having an equipment-grounding conductor and a grounding type
plug. The AC plug must be connected to an appropriate receptacle that is properly installed and
grounded in accordance with the National Electrical Code and all local codes and ordinances. See the
owner’s manual supplied with the charger for specific operating instructions before using the charger.
The use of an extension cord with the charger should be avoided. If an extension cord must be used,
use a three-conductor no. 13 AWG (American Wire Gauge) or no. 15 SWG (British Standard Wire
Gauge), heavy-duty cord with ground, properly wired and in good electrical condition. Keep it as short
as possible (no more than 12 feet (3.7 m)). Place all cords so they will not be stepped on, tripped over,
or otherwise subject to damage or stress.
1.16.4 Charging Batteries
WARNING
⚫ Be sure all wire connections at the receptacle and the fuse link are clean and tight.
⚫ Do not rock or bend the plug. To connect the charger plug to AC power receptacle,
grasp the plug handle and push the plug straight into the receptacle
