2.4 CHASSIS SPECIFICATIONS
Item
Standard
Limit
Steering system
Type
Rack and pinion
----
Front suspension
Shock absorber travel
Spring free length
Spring rate
Stroke
160 mm (6.3 in)
294 mm (11.57 in)
19.04N/mm(1.94kg/mm)
30-140 mm (1.18 ~ 5.51in)
----
----
----
----
Rear suspension
Shock absorber travel
Spring free length
Spring rate
Stroke
120 mm (4.72 in)
168mm (6.61 in)
39.15N/mm (3.99 kg/mm)
62.5N/mm (6.37 kg/mm)
30 ~ 88 mm (1.18 ~ 3.46in)
88 ~ 140mm (3.46 ~ 5.51 in)
----
----
----
----
----
----
Front wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Aluminum Alloy wheel
12×6 AT (min) /14×7 AT (max)
A356
----
----
----
----
----
1.0 mm
(0.04in)
1.0 mm
(0.04 in)
Rear wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Aluminum Alloy wheel
12×8 AT(min) /14×9 AT (max)
A356
----
----
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
Brake lever and brake pedal
Accelerator pedal free play
Brake pedal free play
Parking brake cable free play
2 ~ 3mm (0.079 ~ 0.118 in)
2 ~ 3mm (0.079 ~ 0.118 in)
2 ~ 3 mm (0.079 ~ 0.118 in)
----
----
----
