GreenWorks CU800 - Checking the Constant Velocity Joint Dust Boots; Checking the Steering System

MAINTENANCE AND ADJUSTMENT OF EV CU800 Service Manual
- 72 -
3.2.12 Checking the Constant Velocity Joint Dust Boots
1. Check:
• dust boots ①
Damage Replace.
□
F
Front
□
R
Rear
3.2.13 Checking the Steering System
1. Check:
Place the vehicle on a level surface.
•steering assembly bearings
Try to the steering wheel up and down, and
back and forth.
Excessive play Replace the steering shaft
assembly.
• tie-rod ends
Turn the steering wheel to the left and right
until it stops completely, and then move the
steering wheel slightly in the opposite
direction. Tie-rod end (s) have vertical play
Replace the tie-rod end(s).
• Raise the front end of the vehicle so that there
is no weight on the front wheels.
