GreenWorks CU800 - Panel and Cargo Bed

MALFUNCTION INSPECTION CU800 Service Manual
107
5.1 PANEL AND CARGO BED
Front Panel
No.
Part Name
Qty
Remarks
Removing the front panel
1
Mounting Plate, Headlight
1
2
Nut Holder M6×2
33
3
Socket Hexagon Screw M6×12
4
4
Left Fender, Front Cover I
1
5
Right Fender, Front Cover I
1
6
Front Panel
1
7
Socket Hexagon Screw M6×16
6
8
Cross Large Plate Head Screw M6×16
5
9
Knob Switch
2
10
Rubber Sleeve, Knob Switch
2
11
Cover Of Front Panel
1
