GENERAL INFORMATION CU800 Service Manual
35
Motor and Controller Connection Terminal
Specification Chart
Charger cord, plug, and socket: Visual check for cracks, looseness and abrasion of wire insulation.
Hand check if cable plugs and sockets are loose. If the Error is found, please go to the dealer to
conduct a comprehensive inspection on the charger. Otherwise, heat or short circuit may cause fire.
1.13.2 Performance Checking Items
1. Check if the headlights and its switch work normally.
2. Check if the turn signal and its switch work normally.
3. Check if emergency lights and its switch work normally.
4. Check if the "forward / reverse" switch works normally.
5. Check if the brake pedal or accelerator pedal could automatically return to position.
6. Check the braking performance to ensure that EV can fully stop in a short distance under a stable
and rapid braking force.
7. Check if parking brake pedal can be reliably locked. And when the brake pedal or accelerator pedal
is depressed, the parking brake pedal should be checked if it could be automatically reset.
WARNING:
When the brake pedal is depressed by appropriate pressure, EV should smoothly and
continuously stop.
If the EV suddenly changes lanes or could not stop or suddenly stops or brings about
harsh braking noise, please immediately check and adjust the brake system.
If the power of depressing the brake pedal is strong, the EV would fiercely brake. While if
the power is continuous and moderate, the EV would finish the brake progress moderately.
8. Check if the parking brake function can meet the requirement. When the parking brake pedal is
depressed until it is locked, the EV can stop in a slope no more than 30% (11°) degree.
9. Check if the reverse buzzer works normally. The reverse buzzer will sound as a reminding to the
driver that he is doing the reverse when the Forward/Reverse handle or switch is at the
REVERSE position.
10. Check the steering wheel. If there is any looseness or play in the steering wheel, please adjust it
immediately.
11. Check if there is any abnormal noise during the driving.
12. Check if the maximum speed of the EV does not exceed 30MPH (48km/h). EV is not allowed to
be driven at a speed higher than 30MPH (48km/h).
