MALFUNCTION INSPECTION CU800 Service Manual
108
No.
Part Name
Qty
Remarks
12
Dash Cover
1
13
Dash Board
1
14
Cross Recessed Pan Head Tapping Screw St3.9×10
4
15
Plastic Hinges, Sundry Box
2
16
Sundry Box Cover
1
17
Lock Catch, Sundry Box
1
18
Plain Washer Φ15×Φ22×1.5
2
19
Clip, Cup Sink
1
20
Boot, Cup Sink
1
21
Trim Cover, Shifter
1
22
Socket Hexagon Screw M6×16
6
23
Socket Hexagon Screw M6×20
2
24
Cross Large Plate Head Screw M6×12
2
25
Left-Front Reflector Plate
1
