MALFUNCTION INSPECTION CU800 Service Manual
188
Lithium battery pack
1
Domestic electric control
assembly
2
Hexagon Flange Bolt M10×1.25×20
6
3
Hexagon Flange Locked Nut M10×1.25
6
4
Motor
1
5
Hexagon Flange Bolt M8×30
5
6
Motor mounting bracket
1
7
Hexagon Flange Bolt M8×20
6
8
Rear Bridge Mounting PlateⅠ
1
9
Rear Bridge Mounting PlateⅡ
1
10
Cable motorⅠ
1
Red heat shrinkable tube
Cable motorⅡ
1
Yellow heat shrinkable tube
Cable motor Ⅲ
1
Green heat shrinkable tube
11
Power supply cable
1
Domestic electric control
assembly
Power supply cable
1
12
Charger components
1
13
Charging outlet
1
14
Decorative oil tank opening cover
2
15
Cross Large Plate Head Screw M6×20
4
16
Hexagon Flange Nut M6
4
17
Controller
1
18
Hexagon Flange Bolt M6×16
6
19
Hexagon Flange Bolt M6×25
4
20
Hexagon Flange Locked Nut M6
6
21
Controller Protective Plate
1
22
Seal
1
23
Charging Adapter Cable
1
24
DC-DC
1
25
Controller
1
26
Fuse Link 250A
1
27
Main Contactor
1
