MOTOR AND DRIVING SYSTEM CU800 Service Manual
102
2020
Alarm; reduce current to 100A
2021
Alarm, BMS turn off discharge relay
2022
Discharge temperature difference
Alarm; reduce current to 200A
2023
Alarm; reduce current to 100A
2024
Alarm, BMS turn off discharge relay
2025
Instantaneous discharge overcurrent
Alarm; reduce current to 200A
2026
Alarm; reduce current to 100A
2027
Alarm, BMS turn off discharge relay
2028
Continuous discharge overcurrent
Alarm; reduce current to 200A
2029
Alarm; reduce current to 100A
2030
Alarm, BMS turn off discharge relay
2031
SOC Low
Alarm
2032
Alarm; L mode limit
2033
Alarm, BMS turn off discharge relay
2034
High total charging voltage
Alarm, request current 25A
2035
Alarm, request current 12.5A
2036
Alarm, BMS disconnect charging relay
2037
High charging unit voltage
Alarm, request current 25A
2038
Alarm, request current 12.5A
2039
Alarm, BMS disconnect charging relay
2040
Low total charge voltage
Alarm, request current 25A
2041
Alarm, request current 12.5A
2042
Alarm, BMS disconnect charging relay
2043
Low charging unit voltage
Alarm, request current 25A
2044
Alarm, request current 12.5A
2045
Alarm, BMS disconnect charging relay
2046
Charging unit voltage difference
Alarm, request current 25A
2047
Alarm, request current 12.5A
2048
Alarm, BMS disconnect charging relay
2049
Charging high temperature
Alarm, request current 25A
2050
Alarm, request current 12.5A
2051
Alarm, BMS disconnect charging relay
2052
Charging low temperature
Alarm, request current 25A
2053
Alarm, request current 12.5A
2054
Alarm, BMS disconnect charging relay
2055
Charging temperature difference
Alarm, request current 25A
2056
Alarm, request current 12.5A
2057
Alarm, BMS disconnect charging relay
2058
Charge overcurrent
Alarm, request current 25A
2059
Alarm, request current 12.5A
2060
Alarm, BMS disconnect charging relay
2063
Falling off of electric voltage cable
Alarm, BMS disconnect all relays
2066
Falling off of temperature sensing
cable
Alarm, BMS disconnect all relays
2067
Insulation leakage Error
Alarm
2068
Alarm, L mode limit
2069
Alarm, BMS disconnect all relays
2072
Vehicle communication failure
Alarm, BMS disconnect all relays
2075
Charging communication failure
Alarm, BMS disconnect charging relay
2078
Relay adhesion failure
Alarm, BMS disconnect all relays
