MALFUNCTION INSPECTION CU800 Service Manual
111
Side Cover and Footrest Parts
No.
Part Name
Qty
Remarks
SIDE COVER
1
Front Board I, Seat
1
2
Cross Large Plate Head Screw M6×16
10
3
Left Seat Board I
1
4
Right Seat Board I
1
5
Socket Hexagon Screw M6×16
6
6
Decorative Sheet, Front Left Backplate
1
7
Nut Holder M6×2
33
8
Cross Large Plate Head Screw M6×16
12
9
Rear Left Wheel Regula I
1
