GreenWorks CU800 - Page 199

MALFUNCTION INSPECTION CU800 Service Manual
192
No.
Part Name
Qty
Remarks
12
Lock Catch I, Safety Belt
2
13
Hexagon Flange Bolt M10×1.25×20
2
14
Left Sheath, Safety Belt Socket
1
15
Right Sheath, Safety Belt Socket
1
16
Socket Hexagon Screw M6×16
6
17
Backrest Holder
1
18
Socket Hexagon Screw M6×12
1
19
Hexagon Step Bolt With Pan M10×Φ14×9×25
2
20
Lock Catcher II, Safety Belt
1
21
Seat Belt Bush
2
