FlexxPump4 N/B
10-fold
Lubrication system with 10 lubrication points
D003489
A B C D E
J I H G F
Fig.7-11 Design FlexxPump4 N/B 10-fold
A Lubricating pinion (not included in the
scope of delivery)
F 2. Axis (not included in the scope of de-
livery)
B Lubricating element (not included in the
scope of delivery)
G 2. FlexxPump4N/B
C 1. Axis (not included in the scope of de-
livery)
H Lubrication line diameter 6/3mm
D 1. FlexxPump4N/B I Splitter
E Splitter J 3. Axis (not included in the scope of de-
livery)
