5.6.3 Output signals and external control system
Display in LCD Function Output signal (PIN 4)
OFF switched off low, permanent
PUL switched on high, permanent
PUL flashing Input signal received high, permanent
01…50 Dispensing process low, 10…18s
E1 Oil bellow empty 0.5Hz square wave signal,
permanent
E2 Overpressure low, permanent
E3 Undervoltage/overvolt-
age
low, permanent
E4 internal error low, permanent
Tab.5-5 Output signals external control unit
