5.4.3.3 FlexxPump4 N/B 9-fold
Lubrication system with 9 lubrication points
A B C D E D F
I H G
Fig.5-4 Design FlexxPump4 N/B 9-fold
A Lubricating pinion (not included in the
scope of delivery)
F 2. FlexxPump4N/B
B Lubricating element (not included in the
scope of delivery)
G 3. Axis (not included in the scope of de-
livery)
C 1. FlexxPump4N/B H 2. Axis (not included in the scope of de-
livery)
D Splitter I 1. Axis (not included in the scope of de-
livery)
E Lubrication line diameter 6/3mm
Commissioning
OPERATING MANUAL FlexxPump4N Lubrication
System
3422906891_v1.0_EN-US
47
