5.4.4 Connecting electrical equipment
DANGER
Faulty cabling
The available mains voltage (supply voltage) has to match the specifications
on the rating plate. A faultily connected product can cause material damage,
or serious or even fatal injuries.
• Check the deviation of the electrical circuit.
• Use only fuses with specified amperage.
• Wire the plug according to the diagram.
• Replace the damaged electric cable or plugs promptly
• Have electricians carry out the electric connection tasks
5.4.4.1 Connecting
A
B
C
E D
Fig.5-6 Connect
A FlexxPump4N D Connection assignment
B connector plug E Hydraulic output
C Connection cable
