GUDEL FlexxPump4 N - Tab. 5-1 Connection Assignment in Draining Time Mode or Hour Mode; Tab. 5-2 Connection Assignment in Pulse Mode

PIN Assignment Color
1 Input voltage 24VDC brown
2 No assignment white
3 Ground (GND), 0V blue
4 Output signal black
Tab.5-1 Connection assignment in draining time mode or hour mode
PIN Assignment Color
1 Input voltage 24VDC brown
2 Input signal of external control unit white
3 Ground (GND), 0V blue
4 Output signal to external control unit black
Tab.5-2 Connection assignment in pulse mode
Connect the product as follows:
Prerequisite: The hydraulics are connected
1 Connect the connecting cable to the connector plug
The product is connected
Commissioning OPERATING MANUAL FlexxPump4N Lubrication System
3422906891_v1.0_EN-US
50
