6.6 Sub-menu
6.6.1 SET menu
The SET menu serves to select the operating mode and the bellow volume
used. The operator can choose between the operating modes draining time
mode, hour mode and pulse mode and between bellow volumes 400 ml and
250 ml.
The function is only available if the FlexxPump is switched "OFF". The control
system reverts to "OFF" mode after a completed function.
The standard SET menu setting which Güdel requires calls for draining time
mode as the operating mode and a bellow volume of 400 ml.
2x
SEt
OFF
SEt
-h-
250
Et
2x
Et
400
2x
400
PUL
A B
C BD
Fig.6-2 SET menu
A Operating mode: hour mode C Operating mode: draining time mode
B Bellow volume in milliliters D Operating mode: pulse mode
