GUDEL FlexxPump4 N - Design and Functionality; Product Design Components

4 Design, function
4.1 Design
The product is made up of the following components:
(Further information Ü245)
A
B
C
E D
Fig.4-1 Configuration of FlexxPumpN lubrication system
A FlexxPump D Y-piece (runs the lubricant together)
B Connection cable E Splitter (divides the lubricant)
C Lubrication line
