GUDEL FlexxPump4 N - Draining Time and Hour Mode Activation; Pulse Mode Activation and Control

5.5 Activation in draining time mode or hour
mode
The emptying time mode is accepted as the standard at Güdel. Reference is
made to this operating mode in the lubrication recommendation and in the
lubricant quantity calculator. The details on other operating modes are to be
considered as supplementary information.
5.5.1 Output signals in draining time mode or hour
mode
The output signal at PIN4 in normal operation is High (20…30V).
Other output signals at PIN4 are given as follows:
Display in LCD Function Output signal (PIN 4)
OFF switched off low, permanent
On switched on high, permanent
E1 Oil bellow empty 0.5Hz square wave signal,
permanent
E2 Overpressure low, permanent
E3 Undervoltage/over-
voltage
low, permanent
E4 internal error low, permanent
Tab.5-3 Output signals external control unit
5.6 Activate in pulse mode
The emptying time mode is accepted as the standard at Güdel. Reference is
made to this operating mode in the lubrication recommendation and in the
lubricant quantity calculator. The details on other operating modes are to be
considered as supplementary information.
