GUDEL FlexxPump4 N - Fig. 4 -2 Detailed Configuration of the Flexxpump4 N

4.1.1 Detailed configuration of the FlexxPump4N
The product is made up of the following components:
A
B
C
D
E
F
Fig.4-2 Detailed configuration of the FlexxPump4N
A Cover D Housing
B Oil bellow E Supply and control unit connector plug
C Retaining ring F Hydraulic output
