6.6.8 RUN menu
The RUN menu is used to trigger a special dispensing action. The function en-
ables manual checking of a lubrication point, for example. With the activation,
a special dispensing action per outlet is initiated and the FlexxPump executes
the number of strokes that is set in the PRO menu under the parameter for
number of strokes "c".
The function is only available if the FlexxPump is switched "On". The control
system reverts to "On" mode after a completed function.
If the function is executed while the FlexxPump is in emptying time mode,
the set emptying time is shortened.
2x
run
run
On
01
Fig.6-8 RUN menu
Execute the RUN menu as follows:
Prerequisite: There is no malfunction at the FlexxPump
1 Touch the active surface with the magnetic peg Ü238
2 Remove the magnetic peg from the active surface once the LCD displays
"run" and the yellow LED lights up
3 Wait until the green LED and the LCD flash twice
The FlexxPump executes the RUN menu (a special dispensing action).
The counter-pressure values are displayed in bar on the LCD and the green
LED lights up during the individual strokes.
