GUDEL FlexxPump4 N - Submenu; Tab. 4-2 Character Display Explanation; Tab. 4-3 Explanation of Special Characters; Tab. 4-4 Explanation of INF Menu

Display in LCD Explanation
PUL • The FlexxPump is ready for operation in pulse
mode PUL
• The FlexxPump is waiting for a control signal from
the PLC
PUL (flashing) The FlexxPump is receiving a control signal from the
PLC
--- The control signal received is longer than 15s
Tab.4-2 Character display explanation
Display in LCD Explanation
MAX The maximum counterpressure at hand is displayed
inbar during the dispensing process.
1/2 The FlexxPump shows which hydraulic output the lu-
bricant is being pumped from during the dispensing
process.
Tab.4-3 Explanation of special characters
Submenu
INF menu
Submenu Display in LCD Explanation
INF n41 FlexxPump firmware version
INF h03 The currently set pause time
value "h"
INF c01 The currently set stroke rate
value "c"
INF 06 The currently set draining time
value
INF PUL The operating mode is currently
set to pulse mode
Tab.4-4 Explanation of INF menu
Design, function
OPERATING MANUAL FlexxPump4N Lubrication
System
3422906891_v1.0_EN-US
35
