SERVICE AND REPAIR
GH Combi lock
Check that the safety lock on the fixed rail is installed with
safety screws (1) on the right side.
Check that the safety lock on the fixed rail is installed with
safety screws (1) on the left side.
Check the distance between the rails (1). It must be 3 mm.
Check that the rails are at the same level (2) (Because of
deflection, we recommend that the traverse rail is installed
½-1 mm higher than the fixed rail)
Check that the safety lock’s tongue (1) for the traverse rail
is flush with rail end (2).
