Appendix A Chassis views and technical
specifications
Chassis views
S5130S-10P-EI
Figure 42 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port
(6) SFP port
Figure 43 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
1
3
2
4
5
6
21
