H3C S5130S-EI series - S5130 S-52 Mp-Ei

49
S5130S-52MP-EI
Figure 66 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) 5G/2.5G/1000BASE-T autosensing Ethernet port (5GBASE-T)
(4) Console port
(5) Micro USB console port
(6) System status LED (SYS)
(7) SFP port
(8) SFP port LED
(9) 5G/2.5G/1000BASE-T autosensing Ethernet port LED
Figure 67 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
9
6
7
4
3 5
8
1
2
1 2
