Appendix B FRUs
WARNING!
Y
ou can replace one of the two power modules operating in 1+1 redundancy on the S5130S-28F-
EI
and
S5130S-52F-EI switches. To avoid device damage and bodily injury, make sure the power
module is powered off before removing it.
The S5130S-28F-EI and S5130S-52F-EI switches each provide two power module slots. One power
module can meet the power requirement of the switch. You can install two power modules on the
switch for 1+1 redundancy. Table 21 describes the power modules available for the S5130S-52F-EI
switch.
Table 21 Power modules available for the S5130S-52F-EI switch
Power module
model
Item Specification Remarks
PSR75-12A
Rated input voltage
AC: 100 VAC to 240 VAC
@ 50 Hz or 60 Hz
DC: 240 VDC
For more information about the
power module, see H3C
PSR75-12A Power Module User
Manual.
Max input voltage
AC: 90 VAC to 290 VAC @
47 Hz to 63 Hz
DC: 180 VDC to 320 VDC
Max output power 75 W
PSR150-A1
Rated input voltage
100 VAC to 240 VAC @ 50
Hz or 60 Hz
For more information about the
power modules, see H3C
PSR150-A & PSR150-D Series
Power Modules User Manual.
Max input voltage
90 VAC to 264 VAC @ 47
Hz to 63 Hz
Max output power 150 W
PSR150-D1
Rated input voltage –48 VDC to –60 VDC
Max input voltage –36 VDC to –72 VDC
Max output power 150 W
Appendix C Ports and LEDs
Ports
Console port
The following switch models each provide a serial console port and a micro USB console port on the
front panel. The other S5130S-EI switch models each provide only a serial console port.
•
S5130S-28TP-EI
•
S5130S-52TP-EI
•
S5130S-16S-PWR-EI
