H3C S5130S-EI series User Manual

79
Table 26 2.5G/1000/100BASE-T autosensing Ethernet port specifications
Item Specification
Connector type RJ-45
Transmission rate, duplex mode, and
auto MDI/MDI-X
• 2.5 Gbps, full duplex
• 1 Gbps, full duplex
• 100 Mbps, full duplex
• MDI/MDI-X autosensing
Max transmission distance 2.5G mode: 100 m (328.08 ft)
Transmission medium Category-5e (or above) twisted pair cable
Compatible standards
• IEEE 802.3ab
• IEEE 802.3an
10/5/2.5/1GBASE-T autosensing Ethernet port
The S5130S-28ST-EI, S5130S-52ST-EI, S5130S-28ST-PWR-EI, and S5130S-52ST-PWR-EI
switches provide 10/5/2.5/1GBASE-T autosensing Ethernet ports.
Table 27 10/5/2.5/1GBASE-T autosensing Ethernet port specifications
Item Specification
Connector type RJ-45
Transmission rate, duplex mode, and
auto MDI/MDI-X
• 10 Gbps, full duplex
• 5 Gbps, full duplex
• 2.5 Gbps, full duplex
• 1 Gbps, full duplex
• MDI/MDI-X autosensing
Max transmission distance
• Category-6 unshielded twisted pair cable—55 m (180.45
ft)
• Category-6 single-shielded twisted pair cable—100 m
(328.08 ft)
• Category-6 double-shielded twisted pair cable—100 m
(328.08 ft)
• Category-6a (or above) twisted pair cable—100 m (328.08
ft)
Transmission medium Category-6 (or above) twisted pair cable
Compatible standards
• IEEE 802.3ab
• IEEE 802.3an
SFP port
Some S5130S-EI switch models provide SFP ports. Table 28 describes the SFP port support for the
SFP transceiver modules and cables.

H3C S5130S-EI series Specifications

General

Series	S5130S-EI
Category	Switch
MAC Address Table Size	16K
VLAN	4K VLANs
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T ports
Layer Support	Layer 3
Stacking	Supported
Power Supply	AC/DC
PoE	Supported on some models
Dimensions (W x D x H)	440 x 43.6 mm
