57
Figure 87 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
S5130S-28S-PWR-EI
Figure 88 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Port LED mode switching button
(3) 10/100/1000BASE-T autosensing Ethernet port LED
(4) SFP+ port LED
(5) System status LED (SYS)
(6) Mode LED (MODE)
(7) Micro USB console port
(8) Console port
(9) SFP+ port
Figure 89 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
1
2
1
7
9
3
4
8
6
2
5
1 2
