Table 22 Console port specifications
Item Serial console port Micro USB console port
Connector type RJ-45 Micro USB Type B
Compliant standard EIA/TIA-232 USB 2.0
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII
terminal.
• Provides connection to the serial
port of a local PC running terminal
emulation program.
• Provides connection to an
ASCII terminal.
• Provides connection to the USB
port of a local PC running
terminal emulation program.
Management Ethernet port
The S5130S-28F-EI and S5130S-28PS-EI switches each have one management Ethernet port. You
can connect the port to a local PC for software loading and debugging or to a remote management
station for remote management.
Table 23 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Transmission rate, duplex mode,
and auto MDI/MDI-X
• 10 Mbps, half/full duplex
• 100 Mbps, half/full duplex
• MDI/MDI-X autosensing
Max transmission distance 100 m (328.08 ft)
Transmission medium Category-5 (or above) twisted pair cable
Compatible standards
• IEEE 802.3i
• IEEE 802.3u
• IEEE 802.3ab
Functions and services Software upgrade and network management.

H3C S5130S-EI series Specifications

General

Series	S5130S-EI
Category	Switch
MAC Address Table Size	16K
VLAN	4K VLANs
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T ports
Layer Support	Layer 3
Stacking	Supported
Power Supply	AC/DC
PoE	Supported on some models
Dimensions (W x D x H)	440 x 43.6 mm
