S5130S-28PS-EI
Figure 68 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port
(4) Management Ethernet port
(5) Console port
(6) System status LED (SYS)
(7) SFP+ port
(8) SFP+ port LED
(9) Management Ethernet port status LED (ACT/LINK)
(10) SFP port LED
Figure 69 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) DC-input power receptacle
1
2 3 4 65
10
9
7
8
1
32
