S5130S-28P-HPWR-EI
Figure 82 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Console port
(3) Port LED mode switching button
(4) 10/100/1000BASE-T autosensing Ethernet port LED
(5) System status LED (SYS)
(6) RPS status LED (RPS)
(7) Mode LED (MODE)
(8) SFP port LED
(9) SFP port
Figure 83 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) DC-input power receptacle
1
9
3
5
2
8
4
6
7
1
2
3
