H3C S5130S-EI series - S5130 S-28 P-Ei;S5130 S-28 P-Ei-M

42
Figure 47 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
S5130S-28P-EI/S5130S-28P-EI-M
Figure 48 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port
(6) SFP port
Figure 49 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
1 2
1
5
2
3
6
4
2
1
