H3C S5130S-EI series User Manual

75
Item S5130S-28MP-HPWR-EI S5130S-10MS-UPWR-EI
Input voltage
AC power source:
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
DC power source: H3C RPS1600-A
• Rated voltage: –54 VDC to –57 VDC
• Max voltage:
 Single DC input: –44 VDC to –60 VDC
 AC and DC inputs: –54 VDC to –57 VDC
Maximum PoE power per
port
30 W 90 W
Total PoE power
• AC: 370 W
• DC: 740 W
• AC: 370 W
• DC: 740 W
Minimum power
consumption
• AC: 26 W
• DC: 36 W
• AC: 23 W
• DC: 18 W
Maximum power
consumption (including
PoE power consumption)
• AC: 446 W
• DC: 820 W
• AC: 447 W
• DC: 794 W
Chassis leakage current
compliance
UL 60950-1/EN 60950-1/IEC 60950-1/GB 4943/UL 62368-1/EN 62368-1/IEC
62368-1
Melting current of power
module fuse
15 A/250 V
Cooling system
Using fixed fan trays to draw ambient air in from the left side and exhaust
heated air from the right side.
Operating temperature –5°C to +45°C (23°F to 113°F)
Operating humidity 5% to 95%, noncondensing
Fire resistance compliance
UL 60950-1/EN 60950-1/IEC 60950-1/GB 4943/UL 62368-1/EN 62368-1/IEC
62368-1

H3C S5130S-EI series Specifications

General

Series	S5130S-EI
Category	Switch
MAC Address Table Size	16K
VLAN	4K VLANs
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T ports
Layer Support	Layer 3
Stacking	Supported
Power Supply	AC/DC
PoE	Supported on some models
Dimensions (W x D x H)	440 x 43.6 mm
