Haas Mill User Manual

96-8000 rev R June 2007
Safety
3
♦♦
♦♦
♦ Avoid entering the machine enclosure.
♦♦
♦♦
♦ Do not operate without proper training.
♦♦
♦♦
♦ Always wear safety goggles.
♦♦
♦♦
♦ Never place your hand on the tool in the spindle and press ATC FWD, ATC REV,
NEXT TOOL, or cause a tool change cycle. The tool changer will move in and
crush your hand.
♦♦
♦♦
♦ To avoid tool changer damage, ensure that tools are properly aligned with the
spindle drive lugs when loading tools.
♦♦
♦♦
♦ The electrical power must meet the specifications in this manual. Attempting to
run the machine from any other source can cause severe damage and will void the
warranty.
♦♦
♦♦
♦ DO NOT press POWER UP/RESTART on the control panel until after the
installation is complete.
♦♦
♦♦
♦ DO NOT attempt to operate the machine before all of the installation instructions
have been completed.
♦♦
♦♦
♦ NEVER service the machine with the power connected.
♦♦
♦♦
♦ Improperly clamped parts machined at high speeds/feeds may be ejected and
puncture the safety door. Machining oversized or marginally clamped parts is not
safe.
♦♦
♦♦
♦ Windows must be replaced if damaged or severely scratched - Replace damaged
windows immediately.
♦♦
♦♦
♦ Do not process toxic or flammable material. Deadly fumes can be present. Consult
material manufacturer for safe handling of material by-products before processing.
OBSERVE ALL OF THE WARNINGS AND CAUTIONS BELOW:

Haas Mill Specifications

General

Travels X Axis	Varies by model
Travels Y Axis	Varies by model
Travels Z Axis	Varies by model
Spindle Speed	Varies by model
Spindle Motor	Varies by model
Table Size	Varies by model
Rapid Traverse Rates	Varies by model
Tool Capacity	Varies by model
Max Cutting Rate	Varies by model
Spindle Taper	Varies by model
